Red 16

Description

RedPoint: The Portable PBM Solution

The RedPoint device is the first portable, pre-programmed photobiomodulation (PBM) device designed for everyone. It fits comfortably in your hand and uses Actycel Technology to stimulate natural cellular regeneration. This non-invasive PBM technique utilizes low-intensity, specific-spectrum LED light, a method widely supported by peer-reviewed scientific studies for its effectiveness across various applications.

Technical Specifications

Use, Storage, and Transport

• Temperature: −15∘C to +40∘C
• Humidity: Max. $90\%$ without condensation

Device Specifications (RED16)

• Photobiomodulation device
• LED device with touch display
• Product Dimensions: $130\times 73\times 30\text{mm}$
• Power Consumption: $6.5\text{W}$
• Standby Power Consumption: $0.076\text{W}$
• Light Type: Red LED photobiomodulation device ($600–660\text{nm}$)

Compliance and Certifications

EC Declaration of Conformity

The RED16 complies with the following European directives:

• Directive 2014/30/EU (EMC)
• Directive 2011/65/EU (RoHS 3)
• Directive 2014/35/EU (Low Voltage)

The CE marking indicates conformity with all essential requirements.

Harmonised Standards

• This product complies with the emission & immunity limits according to EN 60601-1-2.
• This LED device complies with EN 62471 on photobiological safety, ensuring that light emissions are safe for skin and eyes under intended use conditions.

Ecodesign Directive Compliance (EU 2019/2021)

This product meets the requirements of the EU Ecodesign Directive 2019/2021, including:

• Standby Consumption: $\le 0.5\text{W}$ (measured: $0.076\text{W}$)
• Optimized Energy Efficiency: Achieved via low-consumption LED technology
• Recyclability: Compliant with WEEE Directive (2012/19/EU)

Box Contents

RED16 Package Includes:

• $4\times$ Connecting Cables
• $16\times$ Mini REDs
• $1\times$ RED16 Device

RED16 is covered by a 2-year guarantee
